LCD750-12-6
CONN TERM RECT TONG 750 MCM #1/2Manufacturer: Panduit Corp
Categories: Lugs
Quality Control: Learn More
Panduit Corp Pan-Lug™ LCD750-12-6 is a non-insulated, rectangular tongue terminal connector designed for high-capacity electrical connections. This component features a 750 MCM (kcmil) wire gauge capacity and is terminated via crimp to a barrel. The connector offers two stud holes, accommodating a 1/2 stud size with a tab thickness of 0.260 inches. Its overall length is 5.650 inches, and the outer edges measure 1.890 inches wide. The mounting type is free hanging (in-line). This terminal is suitable for heavy-duty power distribution and industrial applications, including energy infrastructure and heavy equipment manufacturing. It is supplied in bulk packaging.
Additional Information
Series: Pan-Lug™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Color | Black |
| Mounting Type | Free Hanging (In-Line) |
| Wire Gauge | 750MCM (kcmil) |
| Insulation | Non-Insulated |
| Terminal Type | Rectangular Tongue |
| Stud/Tab Size | 1/2 Stud |
| Length - Overall | 5.650"" (143.51mm) |
| Termination | Crimp, Barrel |
| Width - Outer Edges | 1.890"" (48.01mm) |
| Tab Thickness | 0.260"" (6.60mm) |
| Terminal Style | Two Stud Holes |
