LCD600-12H-6
CONN TERM RECT TONG 600 MCM #1/2Manufacturer: Panduit Corp
Categories: Lugs
Quality Control: Learn More
Panduit Corp Pan-Lug™ LCD600-12H-6 is a non-insulated, rectangular tongue terminal connector designed for heavy-duty electrical applications. This crimp-style lug accommodates 600MCM (kcmil) wire and features a 1/2 stud size for secure mounting. The terminal offers two stud holes with a tab thickness of 0.260" (6.60mm) and an outer width of 1.700" (43.18mm). Its mounting options include free hanging (in-line) and a 45° angle configuration. The Panduit Corp Pan-Lug™ LCD600-12H-6 is suitable for use in power distribution, industrial automation, and utility infrastructure sectors. This component is supplied in bulk packaging.
Additional Information
Series: Pan-Lug™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Color | Green |
| Mounting Type | Free Hanging (In-Line), 45° Angle |
| Wire Gauge | 600MCM (kcmil) |
| Insulation | Non-Insulated |
| Terminal Type | Rectangular Tongue |
| Stud/Tab Size | 1/2 Stud |
| Length - Overall | - |
| Termination | Crimp, Barrel |
| Width - Outer Edges | 1.700"" (43.18mm) |
| Tab Thickness | 0.260"" (6.60mm) |
| Terminal Style | Two Stud Holes |
