LCD6-56DH-L
CONN TERM RECT TONG 6 AWG #5/16Manufacturer: Panduit Corp
Categories: Lugs
Quality Control: Learn More
Panduit Corp Pan-Lug™ Series LCD6-56DH-L is a non-insulated rectangular tongue terminal designed for robust electrical connections. This component accommodates 6 AWG wire, featuring a 5/16 Stud size and a tab thickness of 0.070 inches. The terminal style includes two stud holes, with a barrel termination suitable for crimping. Its outer edges measure 0.560 inches in width. The mounting type is free hanging (in-line) with an option for a 45° angle. This Panduit Corp terminal is commonly utilized in power distribution, industrial automation, and heavy equipment manufacturing sectors. Supplied in bulk packaging, the LCD6-56DH-L offers reliable termination for demanding applications.
Additional Information
Series: Pan-Lug™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Color | Blue |
| Mounting Type | Free Hanging (In-Line), 45° Angle |
| Wire Gauge | 6 AWG |
| Insulation | Non-Insulated |
| Terminal Type | Rectangular Tongue |
| Stud/Tab Size | 5/16 Stud |
| Length - Overall | - |
| Termination | Crimp, Barrel |
| Width - Outer Edges | 0.560"" (14.22mm) |
| Tab Thickness | 0.070"" (1.78mm) |
| Terminal Style | Two Stud Holes |
