LCD6-38DH-L
CONN TERM RECT TONG 6 AWG #3/8Manufacturer: Panduit Corp
Categories: Lugs
Quality Control: Learn More
Panduit Corp Pan-Lug™ LCD6-38DH-L is a non-insulated, rectangular tongue terminal designed for robust electrical connections. This component features a 3/8 stud size and accommodates 6 AWG wire gauge via a crimp barrel termination. The terminal style includes two stud holes, with a tab thickness of 0.060" (1.52mm) and an outer width of 0.620" (15.75mm). Mounting is supported in a free-hanging (in-line) configuration or at a 45° angle. The LCD6-38DH-L is commonly utilized in power distribution, industrial automation, and heavy equipment applications where reliable termination of large gauge conductors is critical. This component is supplied in bulk packaging and is blue in color.
Additional Information
Series: Pan-Lug™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Color | Blue |
| Mounting Type | Free Hanging (In-Line), 45° Angle |
| Wire Gauge | 6 AWG |
| Insulation | Non-Insulated |
| Terminal Type | Rectangular Tongue |
| Stud/Tab Size | 3/8 Stud |
| Length - Overall | - |
| Termination | Crimp, Barrel |
| Width - Outer Edges | 0.620"" (15.75mm) |
| Tab Thickness | 0.060"" (1.52mm) |
| Terminal Style | Two Stud Holes |
