LCD6-10DH-L
CONN TERM RECT TONG 6 AWG #10Manufacturer: Panduit Corp
Categories: Lugs
Quality Control: Learn More
Panduit Corp Pan-Lug™ LCD6-10DH-L is a non-insulated, rectangular tongue terminal connector designed for robust electrical connections. This component is suitable for wire gauges of 6 AWG and features two stud holes, accommodating a #10 stud size. The terminal is manufactured with a tab thickness of 0.080 inches (2.03mm) and an outer width of 0.460 inches (11.68mm). Termination is achieved via crimp, utilizing a barrel connection. The mounting type offers flexibility with options for free hanging (in-line) or a 45° angle. This Panduit Corp component finds application in power distribution and industrial automation sectors where reliable wire termination is critical. It is supplied in bulk packaging.
Additional Information
Series: Pan-Lug™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Color | Blue |
| Mounting Type | Free Hanging (In-Line), 45° Angle |
| Wire Gauge | 6 AWG |
| Insulation | Non-Insulated |
| Terminal Type | Rectangular Tongue |
| Stud/Tab Size | 10 Stud |
| Length - Overall | - |
| Termination | Crimp, Barrel |
| Width - Outer Edges | 0.460"" (11.68mm) |
| Tab Thickness | 0.080"" (2.03mm) |
| Terminal Style | Two Stud Holes |
