LCD350-38DH-X
CONN TERM RECT TONG 350 MCM #3/8Manufacturer: Panduit Corp
Categories: Lugs
Quality Control: Learn More
Panduit Corp Pan-Lug™ rectangular tongue terminal connector, part number LCD350-38DH-X, is engineered for robust electrical connections. This non-insulated, bulk-packaged component accommodates 350 MCM (kcmil) wire with a 3/8 stud size. Featuring a rectangular tongue terminal style with two stud holes, it is designed for crimp barrel termination. The overall width is 1.280 inches (32.51mm) with a tab thickness of 0.170 inches (4.32mm). The mounting type supports free hanging (in-line) or 45° angle configurations. This component is commonly utilized in power distribution, industrial automation, and heavy equipment manufacturing sectors.
Additional Information
Series: Pan-Lug™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Color | Red |
| Mounting Type | Free Hanging (In-Line), 45° Angle |
| Wire Gauge | 350MCM (kcmil) |
| Insulation | Non-Insulated |
| Terminal Type | Rectangular Tongue |
| Stud/Tab Size | 3/8 Stud |
| Length - Overall | - |
| Termination | Crimp, Barrel |
| Width - Outer Edges | 1.280"" (32.51mm) |
| Tab Thickness | 0.170"" (4.32mm) |
| Terminal Style | Two Stud Holes |
