LCD350-12E-X
CONN TERM RECT TONG 350 MCM #1/2Manufacturer: Panduit Corp
Categories: Lugs
Quality Control: Learn More
Panduit Corp Pan-Lug™ series rectangular tongue terminal connector, part number LCD350-12E-X. This non-insulated, bulk-packaged component is engineered for 350 MCM (kcmil) wire termination via crimp barrel. It features a rectangular tongue with two stud holes, accommodating a 1/2 stud size. The overall length is 4.330 inches (109.98mm) with an outer edge width of 1.280 inches (32.51mm) and a tab thickness of 0.170 inches (4.32mm). Designed for free-hanging, in-line mounting, this terminal is suitable for demanding applications in power distribution and industrial automation.
Additional Information
Series: Pan-Lug™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Color | Red |
| Mounting Type | Free Hanging (In-Line) |
| Wire Gauge | 350MCM (kcmil) |
| Insulation | Non-Insulated |
| Terminal Type | Rectangular Tongue |
| Stud/Tab Size | 1/2 Stud |
| Length - Overall | 4.330"" (109.98mm) |
| Termination | Crimp, Barrel |
| Width - Outer Edges | 1.280"" (32.51mm) |
| Tab Thickness | 0.170"" (4.32mm) |
| Terminal Style | Two Stud Holes |
