LCD300-38DH-X
CONN TERM RECT TONG 300 MCM #3/8Manufacturer: Panduit Corp
Categories: Lugs
Quality Control: Learn More
Panduit Corp Pan-Lug™ LCD300-38DH-X is a non-insulated, rectangular tongue terminal connector designed for 300 MCM (kcmil) wire. This bulk-packaged component features a 3/8 stud size with a tab thickness of 0.160 inches (4.06mm). The terminal style includes two stud holes, and termination is achieved via crimp to the barrel. With an outer edge width of 1.190 inches (30.23mm), the LCD300-38DH-X is suitable for free hanging (in-line) or 45° angled mounting. This component is utilized in demanding applications within the power distribution and industrial automation sectors.
Additional Information
Series: Pan-Lug™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Color | White |
| Mounting Type | Free Hanging (In-Line), 45° Angle |
| Wire Gauge | 300MCM (kcmil) |
| Insulation | Non-Insulated |
| Terminal Type | Rectangular Tongue |
| Stud/Tab Size | 3/8 Stud |
| Length - Overall | - |
| Termination | Crimp, Barrel |
| Width - Outer Edges | 1.190"" (30.23mm) |
| Tab Thickness | 0.160"" (4.06mm) |
| Terminal Style | Two Stud Holes |
