LCD2-38AD-Q
CONN TERM RECT TONG 2 AWG #3/8Manufacturer: Panduit Corp
Categories: Lugs
Quality Control: Learn More
Panduit Corp Pan-Lug™ LCD2-38AD-Q is a non-insulated, rectangular tongue terminal connector designed for robust electrical connections. This component is engineered to accept 2 AWG wire gauge via a crimp barrel termination. Featuring a dual stud configuration with a 3/8 stud size, it offers secure mounting options. The overall length measures 3.000 inches (76.20mm) with a tab thickness of 0.100 inches (2.54mm) and an outer edge width of 0.660 inches (16.76mm). The terminal style is a rectangular tongue with two stud holes, facilitating in-line, free-hanging mounting. This Panduit Corp component is commonly utilized in power distribution and industrial automation applications. It is supplied in bulk packaging.
Additional Information
Series: Pan-Lug™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Color | Brown |
| Mounting Type | Free Hanging (In-Line) |
| Wire Gauge | 2 AWG |
| Insulation | Non-Insulated |
| Terminal Type | Rectangular Tongue |
| Stud/Tab Size | 3/8 Stud |
| Length - Overall | 3.000"" (76.20mm) |
| Termination | Crimp, Barrel |
| Width - Outer Edges | 0.660"" (16.76mm) |
| Tab Thickness | 0.100"" (2.54mm) |
| Terminal Style | Two Stud Holes |
