LCD2-14DH-Q
CONN TERM RECT TONG 2 AWG #1/4Manufacturer: Panduit Corp
Categories: Lugs
Quality Control: Learn More
Panduit Corp Pan-Lug™ Rectangular Tongue Terminal Connector, part number LCD2-14DH-Q. This non-insulated terminal features a rectangular tongue with two stud holes, designed for 2 AWG wire gauge. The terminal has a 1/4 Stud size and a tab thickness of 0.100" (2.54mm). Termination is achieved via crimp to a barrel. The overall width of the outer edges is 0.600" (15.24mm). Mounting is suitable for free hanging (in-line) configurations or at a 45° angle. This component is commonly utilized in power distribution, electrical panel building, and heavy equipment manufacturing. Supplied in bulk packaging.
Additional Information
Series: Pan-Lug™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Color | Brown |
| Mounting Type | Free Hanging (In-Line), 45° Angle |
| Wire Gauge | 2 AWG |
| Insulation | Non-Insulated |
| Terminal Type | Rectangular Tongue |
| Stud/Tab Size | 1/4 Stud |
| Length - Overall | - |
| Termination | Crimp, Barrel |
| Width - Outer Edges | 0.600"" (15.24mm) |
| Tab Thickness | 0.100"" (2.54mm) |
| Terminal Style | Two Stud Holes |
