LCD10-38DH-L
CONN TERM RECT TONG 10 AWG #3/8Manufacturer: Panduit Corp
Categories: Lugs
Quality Control: Learn More
Panduit Corp Pan-Lug™ LCD10-38DH-L is a non-insulated, rectangular tongue terminal designed for robust electrical connections. This component supports 10 AWG wire gauge and features a 3/8 stud size with a tab thickness of 0.040" (1.02mm). The terminal type is rectangular tongue with a crimp barrel termination. Its mounting configuration offers flexibility with both free hanging (in-line) and 45° angle options. The overall width of the outer edges is 0.560" (14.22mm). This terminal is commonly utilized in power distribution, industrial automation, and heavy equipment manufacturing sectors for reliable wire termination. Packaged in bulk.
Additional Information
Series: Pan-Lug™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Color | - |
| Mounting Type | Free Hanging (In-Line), 45° Angle |
| Wire Gauge | 10 AWG |
| Insulation | Non-Insulated |
| Terminal Type | Rectangular Tongue |
| Stud/Tab Size | 3/8 Stud |
| Length - Overall | - |
| Termination | Crimp, Barrel |
| Width - Outer Edges | 0.560"" (14.22mm) |
| Tab Thickness | 0.040"" (1.02mm) |
| Terminal Style | Two Stud Holes |
