LCD1-38AD-E
CONN TERM RECT TONG 1 AWG #3/8Manufacturer: Panduit Corp
Categories: Lugs
Quality Control: Learn More
Panduit Corp Pan-Lug™ LCD1-38AD-E is a non-insulated, rectangular tongue terminal connector designed for 1 AWG wire. This component features a two-stud hole configuration for robust termination, with a stud size of 3/8. The overall length is 2.990 inches (75.95mm), and the outer edges measure 0.700 inches (17.78mm) wide. Tab thickness is 0.110 inches (2.79mm). The termination method is crimp, utilizing a barrel design. This component is suitable for applications in power distribution and electrical infrastructure. Supplied in bulk packaging.
Additional Information
Series: Pan-Lug™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Color | Green |
| Mounting Type | Free Hanging (In-Line) |
| Wire Gauge | 1 AWG |
| Insulation | Non-Insulated |
| Terminal Type | Rectangular Tongue |
| Stud/Tab Size | 3/8 Stud |
| Length - Overall | 2.990"" (75.95mm) |
| Termination | Crimp, Barrel |
| Width - Outer Edges | 0.700"" (17.78mm) |
| Tab Thickness | 0.110"" (2.79mm) |
| Terminal Style | Two Stud Holes |
