LCD1-14BH-E
CONN TERM RECT TONG 1 AWG #1/4Manufacturer: Panduit Corp
Categories: Lugs
Quality Control: Learn More
Panduit Corp Pan-Lug™ LCD1-14BH-E is a non-insulated, rectangular tongue terminal designed for reliable electrical connections. This component accommodates 1 AWG wire gauge and features a 1/4 stud size with a tab thickness of 0.110 inches (2.79mm). The overall width across outer edges is 0.700 inches (17.78mm). Termination is achieved via crimp, utilizing a barrel connection. The terminal style includes two stud holes, offering versatility in mounting. It is suitable for free-hanging (in-line) applications, with an option for a 45° angle mounting. This component is commonly utilized in power distribution and electrical infrastructure projects. Supplied in bulk packaging.
Additional Information
Series: Pan-Lug™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Color | Green |
| Mounting Type | Free Hanging (In-Line), 45° Angle |
| Wire Gauge | 1 AWG |
| Insulation | Non-Insulated |
| Terminal Type | Rectangular Tongue |
| Stud/Tab Size | 1/4 Stud |
| Length - Overall | - |
| Termination | Crimp, Barrel |
| Width - Outer Edges | 0.700"" (17.78mm) |
| Tab Thickness | 0.110"" (2.79mm) |
| Terminal Style | Two Stud Holes |
