LCD1-14AH-E
CONN TERM RECT TONG 1 AWG #1/4Manufacturer: Panduit Corp
Categories: Lugs
Quality Control: Learn More
Panduit Corp Pan-Lug™ LCD1-14AH-E is a non-insulated rectangular tongue terminal connector designed for 1 AWG wire. This component, featuring a 0.110" (2.79mm) tab thickness and two stud holes, facilitates reliable termination via crimp barrel connection. The overall width is 0.700" (17.78mm), and it accommodates a 1/4" stud size. Mounting is supported in a free hanging (in-line) configuration or at a 45° angle. This terminal is commonly employed in power distribution, industrial automation, and electrical infrastructure applications requiring robust and secure wire connections. The Panduit Corp Pan-Lug™ series offers durable solutions for demanding electrical environments.
Additional Information
Series: Pan-Lug™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Color | Green |
| Mounting Type | Free Hanging (In-Line), 45° Angle |
| Wire Gauge | 1 AWG |
| Insulation | Non-Insulated |
| Terminal Type | Rectangular Tongue |
| Stud/Tab Size | 1/4 Stud |
| Length - Overall | - |
| Termination | Crimp, Barrel |
| Width - Outer Edges | 0.700"" (17.78mm) |
| Tab Thickness | 0.110"" (2.79mm) |
| Terminal Style | Two Stud Holes |
