LCCX8-14D-L
CONN TERM RECT TONG 8 AWG #1/4Manufacturer: Panduit Corp
Categories: Lugs
Quality Control: Learn More
Panduit Corp Pan-Lug™ LCCX8-14D-L is a non-insulated, rectangular tongue terminal connector designed for crimp barrel termination. This component accommodates 8 AWG wire gauge and features a 1/4 stud size. Its overall length is 2.480 inches (63.00mm) with an outer width of 0.480 inches (12.19mm) and a tab thickness of 0.070 inches (1.78mm). The LCCX8-14D-L is suitable for free-hanging (in-line) applications and utilizes two stud holes for mounting. This terminal is commonly employed in power distribution, telecommunications, and industrial automation sectors. Packaging is provided in bulk.
Additional Information
Series: Pan-Lug™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Color | Red |
| Mounting Type | Free Hanging (In-Line) |
| Wire Gauge | 8 AWG |
| Insulation | Non-Insulated |
| Terminal Type | Rectangular Tongue |
| Stud/Tab Size | 1/4 Stud |
| Length - Overall | 2.480"" (63.00mm) |
| Termination | Crimp, Barrel |
| Width - Outer Edges | 0.480"" (12.19mm) |
| Tab Thickness | 0.070"" (1.78mm) |
| Terminal Style | Two Stud Holes |
