LCCX8-10AB-L
CONN TERM RECT TONG 8 AWG #10Manufacturer: Panduit Corp
Categories: Lugs
Quality Control: Learn More
Panduit Corp Pan-Lug™ LCCX8-10AB-L is a non-insulated, rectangular tongue terminal connector designed for 8 AWG wire. It features a barrel termination style suitable for crimping and is equipped with two stud holes, accommodating a #10 stud size. The overall length is 2.140 inches (54.36mm) with a tab thickness of 0.080 inches (2.03mm) and an outer edge width of 0.410 inches (10.41mm). This component is typically used in industrial power distribution, electrical construction, and heavy equipment manufacturing. The LCCX8-10AB-L is supplied in bulk packaging.
Additional Information
Series: Pan-Lug™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Color | Red |
| Mounting Type | Free Hanging (In-Line) |
| Wire Gauge | 8 AWG |
| Insulation | Non-Insulated |
| Terminal Type | Rectangular Tongue |
| Stud/Tab Size | 10 Stud |
| Length - Overall | 2.140"" (54.36mm) |
| Termination | Crimp, Barrel |
| Width - Outer Edges | 0.410"" (10.41mm) |
| Tab Thickness | 0.080"" (2.03mm) |
| Terminal Style | Two Stud Holes |
