LCCF8-14B-L
CONN TERM RECT TONG 8 AWG #1/4Manufacturer: Panduit Corp
Categories: Lugs
Quality Control: Learn More
Panduit Corp Pan-Lug™ LCCF8-14B-L is a non-insulated rectangular tongue terminal connector designed for reliable electrical connections. This component features a 1/4 stud size and is suitable for 8 AWG wire gauge. The terminal style includes two stud holes, facilitating secure mounting. Termination is achieved via crimp to a barrel. With an overall length of 2.340 inches (59.44mm) and a width of 0.480 inches (12.19mm), it offers a robust connection point. The tab thickness is 0.070 inches (1.78mm). This component is commonly utilized in power distribution, industrial automation, and renewable energy systems. It is supplied in bulk packaging.
Additional Information
Series: Pan-Lug™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Color | Red |
| Mounting Type | Free Hanging (In-Line) |
| Wire Gauge | 8 AWG |
| Insulation | Non-Insulated |
| Terminal Type | Rectangular Tongue |
| Stud/Tab Size | 1/4 Stud |
| Length - Overall | 2.340"" (59.44mm) |
| Termination | Crimp, Barrel |
| Width - Outer Edges | 0.480"" (12.19mm) |
| Tab Thickness | 0.070"" (1.78mm) |
| Terminal Style | Two Stud Holes |
