LCC8-10BW-L
CONN TERM RECT TONG 8 AWG #10Manufacturer: Panduit Corp
Categories: Lugs
Quality Control: Learn More
Panduit Corp Pan-Lug™ LCC8-10BW-L is a non-insulated, rectangular tongue terminal connector designed for robust electrical connections. This component accommodates 8 AWG wire with a dual stud configuration for a 10 stud size. Featuring a crimp barrel termination method, it offers a secure and reliable connection. The overall length is 2.140 inches (54.36mm) with an outer width of 0.410 inches (10.41mm) and a tab thickness of 0.080 inches (2.03mm). The free-hanging, in-line mounting type allows for flexible installation. This terminal is commonly utilized in industrial automation, power distribution, and telecommunications infrastructure. Supplied in bulk packaging.
Additional Information
Series: Pan-Lug™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Color | Red |
| Mounting Type | Free Hanging (In-Line) |
| Wire Gauge | 8 AWG |
| Insulation | Non-Insulated |
| Terminal Type | Rectangular Tongue |
| Stud/Tab Size | 10 Stud |
| Length - Overall | 2.140"" (54.36mm) |
| Termination | Crimp, Barrel |
| Width - Outer Edges | 0.410"" (10.41mm) |
| Tab Thickness | 0.080"" (2.03mm) |
| Terminal Style | Two Stud Holes |
