LCC4-10BWF-L
CONN TERM RECT TONG 2-4 AWG #10Manufacturer: Panduit Corp
Categories: Lugs
Quality Control: Learn More
Panduit Corp Pan-Lug™ LCC4-10BWF-L is a non-insulated rectangular tongue terminal connector designed for robust electrical connections. This component accommodates wire gauges from 2 to 4 AWG and features a 10 stud size for secure termination. The terminal style includes two stud holes, and the termination method is crimp. With a width of 0.550" (13.97mm) and a tab thickness of 0.090" (2.29mm), it offers a substantial contact area. Mounting options include free hanging (in-line) and right angle configurations, providing flexibility in installation. This Panduit Corp terminal is commonly utilized in power distribution, industrial automation, and heavy equipment sectors where reliable wire termination is critical. The LCC4-10BWF-L is supplied in bulk packaging.
Additional Information
Series: Pan-Lug™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Color | Gray |
| Mounting Type | Free Hanging (In-Line), Right Angle |
| Wire Gauge | 2-4 AWG |
| Insulation | Non-Insulated |
| Terminal Type | Rectangular Tongue |
| Stud/Tab Size | 10 Stud |
| Length - Overall | - |
| Termination | Crimp, Barrel |
| Width - Outer Edges | 0.550"" (13.97mm) |
| Tab Thickness | 0.090"" (2.29mm) |
| Terminal Style | Two Stud Holes |
