LCC1-14BW-E
CONN TERM RECT TONG 1 AWG #1/4Manufacturer: Panduit Corp
Categories: Lugs
Quality Control: Learn More
Panduit Corp Pan-Lug™ LCC1-14BW-E is a non-insulated, rectangular tongue terminal connector. Designed for 1 AWG wire, it features a 1/4 stud size and two mounting holes with a 0.110" tab thickness. The overall length is 3.010" (76.45mm) with an outer width of 0.700" (17.78mm). This component utilizes a crimp barrel termination method and is suitable for free hanging (in-line) mounting. The LCC1-14BW-E is commonly employed in industrial power distribution and electrical infrastructure applications, offering reliable termination for heavy-gauge conductors. Supplied in bulk packaging.
Additional Information
Series: Pan-Lug™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Color | Green |
| Mounting Type | Free Hanging (In-Line) |
| Wire Gauge | 1 AWG |
| Insulation | Non-Insulated |
| Terminal Type | Rectangular Tongue |
| Stud/Tab Size | 1/4 Stud |
| Length - Overall | 3.010"" (76.45mm) |
| Termination | Crimp, Barrel |
| Width - Outer Edges | 0.700"" (17.78mm) |
| Tab Thickness | 0.110"" (2.79mm) |
| Terminal Style | Two Stud Holes |
