LCBX250-58-X
CONN TERM RECT TONG 250 MCM #5/8Manufacturer: Panduit Corp
Categories: Lugs
Quality Control: Learn More
Panduit Corp Pan-Lug™ LCBX250-58-X is a non-insulated, single stud hole terminal connector designed for crimp termination of 250MCM (kcmil) wire. This rectangular tongue terminal features a 5/8 stud size and a tab thickness of 0.170 inches (4.32mm). With an overall length of 4.100 inches (104.14mm) and an outer edge width of 1.280 inches (32.51mm), it offers a robust solution for electrical connections. The free hanging (in-line) mounting type facilitates installation in various applications. This component is suitable for use in the power distribution and industrial automation industries.
Additional Information
Series: Pan-Lug™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Color | Yellow |
| Mounting Type | Free Hanging (In-Line) |
| Wire Gauge | 250MCM (kcmil) |
| Insulation | Non-Insulated |
| Terminal Type | Rectangular Tongue |
| Stud/Tab Size | 5/8 Stud |
| Length - Overall | 4.100"" (104.14mm) |
| Termination | Crimp, Barrel |
| Width - Outer Edges | 1.280"" (32.51mm) |
| Tab Thickness | 0.170"" (4.32mm) |
| Terminal Style | Single Stud Hole |
