LCB8-56W-L
CONN TERM RECT TONG 8 AWG #5/16Manufacturer: Panduit Corp
Categories: Lugs
Quality Control: Learn More
Panduit Corp Pan-Lug™ LCB8-56W-L is a non-insulated, single-stud rectangular tongue terminal designed for 8 AWG wire. This crimp-style terminal features a 5/16" stud size with a tab thickness of 0.050". The overall length is 1.600" (40.64mm) and the outer width is 0.600" (15.24mm). It is suitable for free hanging (in-line) applications and is packaged in bulk. This component is commonly utilized in power distribution and electrical interconnection systems across industrial and commercial sectors.
Additional Information
Series: Pan-Lug™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Color | Red |
| Mounting Type | Free Hanging (In-Line) |
| Wire Gauge | 8 AWG |
| Insulation | Non-Insulated |
| Terminal Type | Rectangular Tongue |
| Stud/Tab Size | 5/16 Stud |
| Length - Overall | 1.600"" (40.64mm) |
| Termination | Crimp, Barrel |
| Width - Outer Edges | 0.600"" (15.24mm) |
| Tab Thickness | 0.050"" (1.27mm) |
| Terminal Style | Single Stud Hole |
