LCB750-12-6
CONN TERM RECT TONG 750 MCM #1/2Manufacturer: Panduit Corp
Categories: Lugs
Quality Control: Learn More
Panduit Corp Pan-Lug™ LCB750-12-6 is a non-insulated, rectangular tongue terminal connector designed for high-capacity wire termination. This component features a single 1/2 stud hole and is engineered for crimp barrel termination of 750 MCM (kcmil) wire. Its robust construction includes an overall length of 5.420 inches (137.67mm) and an outer edge width of 1.890 inches (48.01mm), with a tab thickness of 0.260 inches (6.60mm). The LCB750-12-6 is suitable for free-hanging, in-line mounting applications. This terminal connector is commonly utilized in power distribution, industrial automation, and electrical infrastructure sectors where reliable and high-current connections are critical. Packaged in bulk.
Additional Information
Series: Pan-Lug™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Color | Black |
| Mounting Type | Free Hanging (In-Line) |
| Wire Gauge | 750MCM (kcmil) |
| Insulation | Non-Insulated |
| Terminal Type | Rectangular Tongue |
| Stud/Tab Size | 1/2 Stud |
| Length - Overall | 5.420"" (137.67mm) |
| Termination | Crimp, Barrel |
| Width - Outer Edges | 1.890"" (48.01mm) |
| Tab Thickness | 0.260"" (6.60mm) |
| Terminal Style | Single Stud Hole |
