LCB500-58H-6
CONN TERM RECT TONG 500 MCM #5/8Manufacturer: Panduit Corp
Categories: Lugs
Quality Control: Learn More
Panduit Corp Pan-Lug™ LCB500-58H-6 is a non-insulated, rectangular tongue terminal connector designed for 500 MCM (kcmil) wire. This crimp-style lug features a single 5/8 stud hole with a tab thickness of 0.220 inches (5.59mm) and an outer width of 1.540 inches (39.12mm). The terminal is suitable for free hanging (in-line) or 45° angle mounting. Applications for this Panduit Corp component include power distribution and industrial control systems. It is supplied in bulk packaging.
Additional Information
Series: Pan-Lug™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Color | Brown |
| Mounting Type | Free Hanging (In-Line), 45° Angle |
| Wire Gauge | 500MCM (kcmil) |
| Insulation | Non-Insulated |
| Terminal Type | Rectangular Tongue |
| Stud/Tab Size | 5/8 Stud |
| Length - Overall | - |
| Termination | Crimp, Barrel |
| Width - Outer Edges | 1.540"" (39.12mm) |
| Tab Thickness | 0.220"" (5.59mm) |
| Terminal Style | Single Stud Hole |
