LCB4-14H-L
CONN TERM RECT TONG 4 AWG #1/4Manufacturer: Panduit Corp
Categories: Lugs
Quality Control: Learn More
Panduit Corp Pan-Lug™ LCB4-14H-L is a non-insulated, rectangular tongue terminal connector designed for robust electrical connections. This component accommodates 4 AWG wire gauge via a crimp, barrel termination method. It features a single stud hole with a 1/4 inch stud size and a tab thickness of 0.090 inches (2.29mm). The outer width measures 0.550 inches (13.97mm). Mounting is facilitated through a free-hanging, in-line configuration, with an available 45° angle option. This terminal is supplied in bulk packaging and is suitable for applications in power distribution and industrial control systems where reliable termination of heavy gauge conductors is critical.
Additional Information
Series: Pan-Lug™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Color | Gray |
| Mounting Type | Free Hanging (In-Line), 45° Angle |
| Wire Gauge | 4 AWG |
| Insulation | Non-Insulated |
| Terminal Type | Rectangular Tongue |
| Stud/Tab Size | 1/4 Stud |
| Length - Overall | - |
| Termination | Crimp, Barrel |
| Width - Outer Edges | 0.550"" (13.97mm) |
| Tab Thickness | 0.090"" (2.29mm) |
| Terminal Style | Single Stud Hole |
