LCB10-14WF-L
CONN TERM RECT TONG 10 AWG #1/4Manufacturer: Panduit Corp
Categories: Lugs
Quality Control: Learn More
Panduit Corp Pan-Lug™ LCB10-14WF-L is a non-insulated, rectangular tongue terminal designed for reliable electrical connections. This component is engineered for 10 AWG wire and features a 1/4 stud size with a tab thickness of 0.050" (1.27mm). The terminal type is a single stud hole, facilitating secure mounting. Termination is achieved via crimp, with a barrel design for robust wire termination. The outer edges measure 0.420" (10.67mm) in width. Mounting is supported in a free hanging (in-line) or right angle configuration. This Panduit Corp terminal is commonly utilized in power distribution, industrial automation, and electrical infrastructure applications where dependable wire termination is critical. Supplied in bulk packaging.
Additional Information
Series: Pan-Lug™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Color | - |
| Mounting Type | Free Hanging (In-Line), Right Angle |
| Wire Gauge | 10 AWG |
| Insulation | Non-Insulated |
| Terminal Type | Rectangular Tongue |
| Stud/Tab Size | 1/4 Stud |
| Length - Overall | - |
| Termination | Crimp, Barrel |
| Width - Outer Edges | 0.420"" (10.67mm) |
| Tab Thickness | 0.050"" (1.27mm) |
| Terminal Style | Single Stud Hole |
