LCAX8-56H-L
CONN TERM RECT TONG 8 AWG #5/16Manufacturer: Panduit Corp
Categories: Lugs
Quality Control: Learn More
Panduit Corp Pan-Lug™ LCAX8-56H-L is a non-insulated rectangular tongue terminal connector designed for 8 AWG wire. This component features a single stud hole with a 5/16 stud size and a tab thickness of 0.050" (1.27mm). The overall width of the terminal is 0.560" (14.22mm). Termination is achieved via crimping onto the barrel. Mounting can be done in a free hanging (in-line) configuration or at a 45° angle. This terminal connector is suitable for applications in industrial automation, power distribution, and telecommunications infrastructure. It is supplied in bulk packaging.
Additional Information
Series: Pan-Lug™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Color | Red |
| Mounting Type | Free Hanging (In-Line), 45° Angle |
| Wire Gauge | 8 AWG |
| Insulation | Non-Insulated |
| Terminal Type | Rectangular Tongue |
| Stud/Tab Size | 5/16 Stud |
| Length - Overall | - |
| Termination | Crimp, Barrel |
| Width - Outer Edges | 0.560"" (14.22mm) |
| Tab Thickness | 0.050"" (1.27mm) |
| Terminal Style | Single Stud Hole |
