LCAX750-12H-3
CONN TERM RECT TONG 750 MCM #1/2Manufacturer: Panduit Corp
Categories: Lugs
Quality Control: Learn More
Panduit Corp Pan-Lug™ LCAX750-12H-3 is a non-insulated rectangular tongue terminal connector designed for crimp barrel termination. This component is engineered for 750MCM (kcmil) wire gauge, featuring a single 1/2 stud hole for secure mounting. The terminal offers a robust construction with a tab thickness of 0.320 inches (8.13mm) and an overall width of 2.170 inches (55.12mm). Its mounting options support free hanging (in-line) or a 45° angle configuration. This high-capacity lug is commonly utilized in power distribution and industrial automation applications. The LCAX750-12H-3 is supplied in bulk packaging.
Additional Information
Series: Pan-Lug™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Color | Yellow |
| Mounting Type | Free Hanging (In-Line), 45° Angle |
| Wire Gauge | 750MCM (kcmil) |
| Insulation | Non-Insulated |
| Terminal Type | Rectangular Tongue |
| Stud/Tab Size | 1/2 Stud |
| Length - Overall | - |
| Termination | Crimp, Barrel |
| Width - Outer Edges | 2.170"" (55.12mm) |
| Tab Thickness | 0.320"" (8.13mm) |
| Terminal Style | Single Stud Hole |
Request a Quote
