LCAX650-58H-6
CONN TERM RECT TONG 650 MCM #5/8Manufacturer: Panduit Corp
Categories: Lugs
Quality Control: Learn More
Panduit Corp Pan-Lug™ LCAX650-58H-6 is a non-insulated, single stud hole rectangular tongue terminal connector designed for crimp barrel termination. This component is engineered for heavy-duty applications, accommodating wire gauges up to 650MCM (kcmil). It features a 5/8 stud size and a tab thickness of 0.300 inches (7.62mm), with an outer edge width of 1.950 inches (49.53mm). The mounting type offers flexibility with options for free hanging (in-line) or a 45° angle. This terminal connector is commonly utilized in industrial power distribution, renewable energy systems, and heavy equipment manufacturing. The LCAX650-58H-6 is supplied in bulk packaging.
Additional Information
Series: Pan-Lug™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Color | Black |
| Mounting Type | Free Hanging (In-Line), 45° Angle |
| Wire Gauge | 650MCM (kcmil) |
| Insulation | Non-Insulated |
| Terminal Type | Rectangular Tongue |
| Stud/Tab Size | 5/8 Stud |
| Length - Overall | - |
| Termination | Crimp, Barrel |
| Width - Outer Edges | 1.950"" (49.53mm) |
| Tab Thickness | 0.300"" (7.62mm) |
| Terminal Style | Single Stud Hole |
