LCAX500-38H-6
CONN TERM RECT TONG 500 MCM #3/8Manufacturer: Panduit Corp
Categories: Lugs
Quality Control: Learn More
Panduit Corp Pan-Lug™ LCAX500-38H-6 is a non-insulated, rectangular tongue terminal connector designed for high-capacity wire termination. This component features a single stud hole suitable for a 3/8 stud and accommodates wire gauges up to 500MCM (kcmil). The termination method is crimp, utilizing a barrel design for secure and reliable connections. With a tab thickness of 0.260" (6.60mm) and an outer width of 1.890" (48.01mm), it provides robust contact for demanding applications. The mounting type offers flexibility with options for free hanging (in-line) or a 45° angle. This terminal connector is commonly utilized in power distribution, industrial automation, and heavy electrical infrastructure. It is supplied in bulk packaging.
Additional Information
Series: Pan-Lug™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Color | Pink |
| Mounting Type | Free Hanging (In-Line), 45° Angle |
| Wire Gauge | 500MCM (kcmil) |
| Insulation | Non-Insulated |
| Terminal Type | Rectangular Tongue |
| Stud/Tab Size | 3/8 Stud |
| Length - Overall | - |
| Termination | Crimp, Barrel |
| Width - Outer Edges | 1.890"" (48.01mm) |
| Tab Thickness | 0.260"" (6.60mm) |
| Terminal Style | Single Stud Hole |
