LCAX350-58H-6
CONN TERM RECT TONG 350 MCM #5/8Manufacturer: Panduit Corp
Categories: Lugs
Quality Control: Learn More
Panduit Corp Pan-Lug™ LCAX350-58H-6 is a non-insulated, rectangular tongue terminal connector designed for high-capacity electrical connections. This component accommodates 350MCM (kcmil) wire gauge and features a single 5/8 stud hole for mounting. The terminal style is a rectangular tongue with a barrel termination suitable for crimping. Key dimensions include an outer edge width of 1.540 inches (39.12mm) and a tab thickness of 0.220 inches (5.59mm). The mounting type offers flexibility with options for free hanging (in-line) or a 45° angle placement. This product is typically utilized in industrial power distribution, heavy equipment, and renewable energy applications where robust and reliable electrical termination is critical. It is supplied in bulk packaging.
Additional Information
Series: Pan-Lug™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Color | Blue |
| Mounting Type | Free Hanging (In-Line), 45° Angle |
| Wire Gauge | 350MCM (kcmil) |
| Insulation | Non-Insulated |
| Terminal Type | Rectangular Tongue |
| Stud/Tab Size | 5/8 Stud |
| Length - Overall | - |
| Termination | Crimp, Barrel |
| Width - Outer Edges | 1.540"" (39.12mm) |
| Tab Thickness | 0.220"" (5.59mm) |
| Terminal Style | Single Stud Hole |
