LCAX250-56H-X
CONN TERM RECT TONG 250MCM #5/16Manufacturer: Panduit Corp
Categories: Lugs
Quality Control: Learn More
Panduit Corp Pan-Lug™ LCAX250-56H-X is a non-insulated, rectangular tongue terminal designed for robust electrical connections. This component features a single stud hole accommodating a 5/16 stud size with a tab thickness of 0.170 inches. Engineered for crimp barrel termination, it supports wire gauges up to 250MCM (kcmil). The terminal's outer edges measure 1.280 inches in width. Mounting options include free hanging (in-line) and a 45° angle configuration. This terminal is commonly utilized in power distribution, industrial automation, and heavy equipment manufacturing sectors where reliable, high-current terminations are critical. The LCAX250-56H-X is supplied in bulk packaging.
Additional Information
Series: Pan-Lug™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Color | Yellow |
| Mounting Type | Free Hanging (In-Line), 45° Angle |
| Wire Gauge | 250MCM (kcmil) |
| Insulation | Non-Insulated |
| Terminal Type | Rectangular Tongue |
| Stud/Tab Size | 5/16 Stud |
| Length - Overall | - |
| Termination | Crimp, Barrel |
| Width - Outer Edges | 1.280"" (32.51mm) |
| Tab Thickness | 0.170"" (4.32mm) |
| Terminal Style | Single Stud Hole |
