LCAS3/0-38H-X
CONN TERM RECT TONG 3/0 AWG #3/8Manufacturer: Panduit Corp
Categories: Lugs
Quality Control: Learn More
The Panduit Corp Pan-Lug™ LCAS3-0-38H-X is a non-insulated, rectangular tongue terminal designed for terminating 3/0 AWG stranded copper wire. This lug features a 3/8 inch stud hole and a barrel termination method requiring crimping. Its construction includes a 0.130 inch tab thickness and an overall width of 0.960 inches. The LCAS3-0-38H-X is suitable for free-hanging, in-line mounting or can be oriented at a 45° angle. This component is typically utilized in power distribution and electrical infrastructure applications. It is supplied in bulk packaging.
Additional Information
Series: Pan-Lug™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Color | Orange |
| Mounting Type | Free Hanging (In-Line), 45° Angle |
| Wire Gauge | 3/0 AWG |
| Insulation | Non-Insulated |
| Terminal Type | Rectangular Tongue |
| Stud/Tab Size | 3/8 Stud |
| Length - Overall | - |
| Termination | Crimp, Barrel |
| Width - Outer Edges | 0.960"" (24.38mm) |
| Tab Thickness | 0.130"" (3.30mm) |
| Terminal Style | Single Stud Hole |
