LCAS3/0-38-X
CONN TERM RECT TONG 3/0 AWG #3/8Manufacturer: Panduit Corp
Categories: Lugs
Quality Control: Learn More
Panduit Corp's Pan-Lug™ LCAS3-0-38-X is a non-insulated, single stud hole rectangular tongue terminal designed for crimp termination. This component is rated for 3/0 AWG wire and features a 3/8 stud size with a tab thickness of 0.130 inches. The overall length is 2.030 inches, and the outer width is 0.960 inches. Its free hanging (in-line) mounting type and bulk packaging make it suitable for high-volume applications. This terminal is commonly utilized in power distribution, electrical infrastructure, and heavy equipment manufacturing.
Additional Information
Series: Pan-Lug™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Color | Orange |
| Mounting Type | Free Hanging (In-Line) |
| Wire Gauge | 3/0 AWG |
| Insulation | Non-Insulated |
| Terminal Type | Rectangular Tongue |
| Stud/Tab Size | 3/8 Stud |
| Length - Overall | 2.030"" (51.56mm) |
| Termination | Crimp, Barrel |
| Width - Outer Edges | 0.960"" (24.38mm) |
| Tab Thickness | 0.130"" (3.30mm) |
| Terminal Style | Single Stud Hole |
