LCAS2-14-Q
CONN TERM RECT TONG 2 AWG #1/4Manufacturer: Panduit Corp
Categories: Lugs
Quality Control: Learn More
Panduit Corp Pan-Lug™ LCAS2-14-Q is a non-insulated, single stud hole, rectangular tongue terminal connector designed for 2 AWG wire. This bulk-packaged component features a 1/4 stud size and a tab thickness of 0.100 inches. The overall length is 1.460 inches with an outer width of 0.600 inches. Termination is achieved via crimp to the barrel. This component is suitable for applications in industrial automation, power distribution, and electrical infrastructure.
Additional Information
Series: Pan-Lug™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Color | Brown |
| Mounting Type | Free Hanging (In-Line) |
| Wire Gauge | 2 AWG |
| Insulation | Non-Insulated |
| Terminal Type | Rectangular Tongue |
| Stud/Tab Size | 1/4 Stud |
| Length - Overall | 1.460"" (37.08mm) |
| Termination | Crimp, Barrel |
| Width - Outer Edges | 0.600"" (15.24mm) |
| Tab Thickness | 0.100"" (2.54mm) |
| Terminal Style | Single Stud Hole |
