LCAF1-56H-X
CONN TERM RECT TONG 1 AWG #5/16Manufacturer: Panduit Corp
Categories: Lugs
Quality Control: Learn More
Panduit Corp Pan-Lug™ LCAF1-56H-X is a non-insulated, single stud hole rectangular tongue terminal designed for 1 AWG wire. This crimp barrel termination component features a 5/16 stud size with a tab thickness of 0.120" (3.05mm) and an outer width of 0.800" (20.32mm). The LCAF1-56H-X is suitable for free hanging (in-line) mounting and can be oriented at a 45° angle. This component is commonly utilized in industrial, power distribution, and electrical equipment applications. It is supplied in bulk packaging.
Additional Information
Series: Pan-Lug™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Color | Pink |
| Mounting Type | Free Hanging (In-Line), 45° Angle |
| Wire Gauge | 1 AWG |
| Insulation | Non-Insulated |
| Terminal Type | Rectangular Tongue |
| Stud/Tab Size | 5/16 Stud |
| Length - Overall | - |
| Termination | Crimp, Barrel |
| Width - Outer Edges | 0.800"" (20.32mm) |
| Tab Thickness | 0.120"" (3.05mm) |
| Terminal Style | Single Stud Hole |
