LCA10-14H-L
CONN TERM RECT TONG 10 AWG #1/4Manufacturer: Panduit Corp
Categories: Lugs
Quality Control: Learn More
Panduit Corp Pan-Lug™ LCA10-14H-L is a non-insulated rectangular tongue terminal connector designed for 10 AWG wire. This component features a single stud hole with a 1/4" stud size and a tab thickness of 0.050" (1.27mm). The overall width across outer edges is 0.420" (10.67mm). Termination is achieved via crimp to a barrel. The mounting type is free hanging (in-line) with a 45° angle option. This terminal is commonly employed in power distribution, electrical enclosures, and industrial automation applications. It is supplied in bulk packaging.
Additional Information
Series: Pan-Lug™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Color | - |
| Mounting Type | Free Hanging (In-Line), 45° Angle |
| Wire Gauge | 10 AWG |
| Insulation | Non-Insulated |
| Terminal Type | Rectangular Tongue |
| Stud/Tab Size | 1/4 Stud |
| Length - Overall | - |
| Termination | Crimp, Barrel |
| Width - Outer Edges | 0.420"" (10.67mm) |
| Tab Thickness | 0.050"" (1.27mm) |
| Terminal Style | Single Stud Hole |
