CX400-12T-3Y
CONN TERM RECT LUG 4/0 AWG #1/2Manufacturer: Panduit Corp
Categories: Lugs
Quality Control: Learn More
Panduit Corp CX Series CX400-12T-3Y rectangular lug terminal, designed for grounding applications. This non-insulated lug accommodates wire gauges from 500 kcmil down to 4/0 AWG and features a 1/2 stud size with a 0.190" (4.83mm) tab thickness. The single stud hole terminal type ensures secure termination via screw. With an overall width of 1.500" (38.10mm), this component is suitable for free hanging (in-line) mounting. Applications include power distribution, industrial automation, and renewable energy systems. Packaged in bulk.
Additional Information
Series: CXRoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Features | With Screw |
| Packaging | Bulk |
| Color | - |
| Mounting Type | Free Hanging (In-Line) |
| Wire Gauge | 500MCM (kcmil)-4/0 AWG |
| Insulation | Non-Insulated |
| Terminal Type | Lug, Grounding |
| Stud/Tab Size | 1/2 Stud |
| Length - Overall | - |
| Termination | Screw |
| Width - Outer Edges | 1.500"" (38.10mm) |
| Tab Thickness | 0.190"" (4.83mm) |
| Terminal Style | Single Stud Hole |
Request a Quote
