CX35-36-CY
CONN TERM RECT LUG 6-14AWG #3/16Manufacturer: Panduit Corp
Categories: Lugs
Quality Control: Learn More
Panduit Corp CX Series CX35-36-CY is a non-insulated, rectangular lug terminal designed for grounding applications. This component accepts wire gauges from 6 to 14 AWG and features a 3/16 stud size with a tab thickness of 0.070 inches (1.78mm). The terminal style is a single stud hole with a termination via screw. Its overall width is 0.380 inches (9.65mm), and it is suitable for free hanging (in-line) mounting. This lug is commonly utilized in power distribution, industrial automation, and electrical infrastructure. It is supplied in bulk packaging.
Additional Information
Series: CXRoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | With Screw |
| Packaging | Bulk |
| Color | - |
| Mounting Type | Free Hanging (In-Line) |
| Wire Gauge | 6-14 AWG |
| Insulation | Non-Insulated |
| Terminal Type | Lug, Grounding |
| Stud/Tab Size | 3/16 Stud |
| Length - Overall | - |
| Termination | Screw |
| Width - Outer Edges | 0.380"" (9.65mm) |
| Tab Thickness | 0.070"" (1.78mm) |
| Terminal Style | Single Stud Hole |
