BML2-95-12
COMPRESSION CONN FOR WIRE ALUMManufacturer: Panduit Corp
Categories: Lugs
Quality Control: Learn More
Panduit Corp BML2 Series ring terminal, part number BML2-95-12, is a non-insulated, single stud hole compression connector designed for aluminum wire applications. This component is engineered for 3/0 AWG wire and features a 12 Stud size with a 0.197" (5.00mm) tab thickness. The overall length is 3.740" (95.00mm) with an outer width of 0.944" (24.00mm). Termination is achieved via crimp. This terminal is suitable for free hanging (in-line) mounting and is supplied in bulk packaging. It finds application in power distribution and industrial control systems.
Additional Information
Series: BML2RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Color | - |
| Mounting Type | Free Hanging (In-Line) |
| Wire Gauge | 3/0 AWG |
| Insulation | Non-Insulated |
| Terminal Type | Ring |
| Stud/Tab Size | 12 Stud |
| Length - Overall | 3.740"" (95.00mm) |
| Termination | Crimp |
| Width - Outer Edges | 0.944"" (24.00mm) |
| Tab Thickness | 0.197"" (5.00mm) |
| Terminal Style | Single Stud Hole |
