MAZ40510MF
DIODE ZENER 5.1V 370MW DO34Manufacturer: Panasonic Electronic Components
Categories: Single Zener Diodes
Quality Control: Learn More
Panasonic Electronic Components MAZ40510MF is a Zener diode with a nominal breakdown voltage of 5.1V. This component offers a power dissipation rating of 370mW and a tolerance of ±6%. It exhibits a reverse leakage current of 2 µA at 2V and a maximum Zener impedance (Zzt) of 60 Ohms. With a forward voltage of 900mV at 10mA, the MAZ40510MF is housed in a DO-34-A2 axial package suitable for through-hole mounting. This device is commonly employed in voltage regulation and surge protection circuits across various industrial applications. The component is supplied in Tape & Box packaging.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Box (TB)Download Free CAD Model:
Technical Details:
| Tolerance | ±6% |
| Packaging | Tape & Box (TB) |
| Package / Case | DO-204AG, DO-34, Axial |
| Mounting Type | Through Hole |
| Operating Temperature | - |
| Voltage - Zener (Nom) (Vz) | 5.1 V |
| Impedance (Max) (Zzt) | 60 Ohms |
| Supplier Device Package | DO34-A2 |
| Power - Max | 370 mW |
| Voltage - Forward (Vf) (Max) @ If | 900 mV @ 10 mA |
| Current - Reverse Leakage @ Vr | 2 µA @ 2 V |
