MA3S132A0L
DIODE GP 80V 100MA SSMINI3-F2Manufacturer: Panasonic Electronic Components
Categories: Single Diodes
Quality Control: Learn More
Panasonic Electronic Components, MA3S132A0L, a general-purpose diode, offers robust performance in a compact SSMini3-F2 package. This surface-mount component features a maximum DC reverse voltage of 80V and a forward voltage of 1.2V at 100mA. Its average rectified current capability is 100mA, with a low reverse leakage of 100nA at 75V. The diode exhibits a reverse recovery time of 3ns, suitable for signal processing applications. With a junction operating temperature up to 150°C, it finds utility in consumer electronics and industrial control systems where compact, reliable signal rectification is essential. The component is supplied on tape and reel for automated assembly processes.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | SC-89, SOT-490 |
| Mounting Type | Surface Mount |
| Speed | Small Signal =< 200mA (Io), Any Speed |
| Reverse Recovery Time (trr) | 3 ns |
| Technology | Standard |
| Capacitance @ Vr, F | 2pF @ 0V, 1MHz |
| Current - Average Rectified (Io) | 100mA |
| Supplier Device Package | SSMini3-F2 |
| Operating Temperature - Junction | 150°C (Max) |
| Voltage - DC Reverse (Vr) (Max) | 80 V |
| Voltage - Forward (Vf) (Max) @ If | 1.2 V @ 100 mA |
| Current - Reverse Leakage @ Vr | 100 nA @ 75 V |
