DB2J40700L
DIODE SCHOT 40V 500MA SMINI2Manufacturer: Panasonic Electronic Components
Categories: Single Diodes
Quality Control: Learn More
Diode 40 V 500mA Surface Mount SMini2-F5-B
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: 11 week(s)Product Status: DiscontinuedPackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | SC-90, SOD-323F |
| Mounting Type | Surface Mount |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | 3.6 ns |
| Technology | Schottky |
| Capacitance @ Vr, F | 10.5pF @ 10V, 1MHz |
| Current - Average Rectified (Io) | 500mA |
| Supplier Device Package | SMini2-F5-B |
| Operating Temperature - Junction | 125°C (Max) |
| Voltage - DC Reverse (Vr) (Max) | 40 V |
| Voltage - Forward (Vf) (Max) @ If | 550 mV @ 500 mA |
| Current - Reverse Leakage @ Vr | 100 µA @ 35 V |
