DB2G42900L1
DIODE SCHOTTKY 40V 1A 0402Manufacturer: Panasonic Electronic Components
Categories: Single Diodes
Quality Control: Learn More
Panasonic Electronic Components DB2G42900L1 is a Schottky diode designed for high-frequency rectification. This component features a 40V reverse voltage rating and a 1A average forward current capability. The forward voltage drop is specified at a maximum of 520mV at 1A. With a reverse leakage of 150 µA at 40V, it offers efficient operation. The diode exhibits a reverse recovery time of 8.8 ns, classifying it as a fast recovery type. Its low capacitance of 28pF at 10V and 1MHz makes it suitable for high-speed switching applications. The device is housed in a compact 0402 (1005 Metric) package, specifically the DCSP1006010-N1, and is supplied on tape and reel for automated assembly. This diode finds application in power management circuits, voltage clamping, and signal rectification within consumer electronics and telecommunications equipment. The maximum operating junction temperature is 150°C.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 13 week(s)Product Status: DiscontinuedPackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 0402 (1005 Metric) |
| Mounting Type | Surface Mount |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | 8.8 ns |
| Technology | Schottky |
| Capacitance @ Vr, F | 28pF @ 10V, 1MHz |
| Current - Average Rectified (Io) | 1A |
| Supplier Device Package | DCSP1006010-N1 |
| Operating Temperature - Junction | 150°C (Max) |
| Voltage - DC Reverse (Vr) (Max) | 40 V |
| Voltage - Forward (Vf) (Max) @ If | 520 mV @ 1 A |
| Current - Reverse Leakage @ Vr | 150 µA @ 40 V |
