PNZ147
SENSOR PHOTO 800NM TOP VIEW AXLManufacturer: Panasonic Electronic Components
Categories: Phototransistors
Quality Control: Learn More
Panasonic Electronic Components PNZ147 is an axial, top-view phototransistor designed for robust optical sensing applications. This component features a peak spectral sensitivity at 800nm, making it suitable for systems utilizing infrared light sources. With a maximum collector current of 20 mA and a breakdown voltage of 20 V, the PNZ147 offers reliable performance in demanding environments. The low dark current of 500 nA (max) ensures accurate signal detection even in low-light conditions. Its through-hole mounting and flat lead package facilitate straightforward integration into printed circuit boards. The 48° viewing angle provides a defined detection area for precise optical feedback. This phototransistor finds application in areas such as industrial automation, consumer electronics, and optical communication systems.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: -Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | - |
| Package / Case | Axial, Flat Leads |
| Wavelength | 800nm |
| Mounting Type | Through Hole |
| Orientation | Top View |
| Operating Temperature | - |
| Viewing Angle | 48° |
| Current - Dark (Id) (Max) | 500 nA |
| Current - Collector (Ic) (Max) | 20 mA |
| Voltage - Collector Emitter Breakdown (Max) | 20 V |
| Power - Max | 50 mW |
