AN78L15
IC REG LINEAR 15V 100MA 3SSIPManufacturer: Panasonic Electronic Components
Categories: Linear, Low Drop Out (LDO) Regulators
Quality Control: Learn More
Panasonic Electronic Components AN78L15 is a positive fixed output linear voltage regulator IC. This device offers a stable 15V output with a maximum current capability of 100mA. Designed for through-hole mounting in a TO-226-3, TO-92-3 (TO-226AA) package, it is suitable for applications requiring reliable voltage regulation. Key features include over-current and over-temperature protection, ensuring robust operation. With a quiescent current of 3.5mA and a maximum input voltage of 35V, the AN78L15 is well-suited for use in consumer electronics, industrial controls, and automotive systems where dependable power management is critical.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | TO-226-3, TO-92-3 (TO-226AA) |
| Output Type | Fixed |
| Mounting Type | Through Hole |
| Current - Output | 100mA |
| Operating Temperature | 0°C ~ 125°C |
| Output Configuration | Positive |
| Current - Quiescent (Iq) | 3.5 mA |
| Voltage - Input (Max) | 35V |
| Number of Regulators | 1 |
| Supplier Device Package | 3-SSIP |
| Voltage - Output (Max) | - |
| Voltage - Output (Min/Fixed) | 15V |
| Control Features | - |
| PSRR | 48dB (120Hz) |
| Voltage Dropout (Max) | - |
| Protection Features | Over Current, Over Temperature |
