AN78L09M
IC REG LINEAR 9V 100MA 3HSIPManufacturer: Panasonic Electronic Components
Categories: Linear, Low Drop Out (LDO) Regulators
Quality Control: Learn More
The Panasonic Electronic Components AN78L09M is a positive fixed output linear voltage regulator. This 3-lead HSIP device provides a stable 9V output with a maximum current capability of 100mA. It features overload protection including over current and over temperature shutdown. The AN78L09M exhibits a typical quiescent current of 3mA and a Power Supply Rejection Ratio (PSRR) of 53dB at 120Hz. Designed for industrial and consumer electronics applications, it supports input voltages up to 35V. The component is supplied in bulk packaging for efficient integration into manufacturing processes.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | TO-243AA |
| Output Type | Fixed |
| Mounting Type | Surface Mount |
| Current - Output | 100mA |
| Operating Temperature | 0°C ~ 125°C |
| Output Configuration | Positive |
| Current - Quiescent (Iq) | 3 mA |
| Voltage - Input (Max) | 35V |
| Number of Regulators | 1 |
| Supplier Device Package | 3-HSIP |
| Voltage - Output (Max) | - |
| Voltage - Output (Min/Fixed) | 9V |
| Control Features | - |
| PSRR | 53dB (120Hz) |
| Voltage Dropout (Max) | - |
| Protection Features | Over Current, Over Temperature |
