LNJ03004GDD1
LED COOL WHITE 6500K 3230Manufacturer: Panasonic Electronic Components
Categories: LED White Lighting
Quality Control: Learn More
Panasonic Electronic Components LNJ03004GDD1, a cool white LED with a Correlated Color Temperature (CCT) of 6500K, is available in a 1212 (3030 Metric) package. This surface mount component operates with a typical forward voltage of 6.2V and a test current of 75mA, delivering 59 lumens with a typical luminous efficacy of 127 lm/W. The LED features a typical Color Rendering Index (CRI) of 82. Its dimensions are 3.00mm x 3.00mm, with a maximum seated height of 0.80mm. The maximum forward current is rated at 120mA. This component is commonly utilized in general illumination and backlighting applications. Supplied in Tape & Reel (TR) packaging.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 1212 (3030 Metric) |
| Color | White, Cool |
| Size / Dimension | 0.118"" L x 0.118"" W (3.00mm x 3.00mm) |
| Mounting Type | Surface Mount |
| Voltage - Forward (Vf) (Typ) | 6.2V |
| Current - Test | 75mA |
| Viewing Angle | - |
| Current - Max | 120mA |
| Supplier Device Package | 3230 |
| Lumens/Watt @ Current - Test | 127 lm/W |
| Height - Seated (Max) | 0.031"" (0.80mm) |
| CCT (K) | 6500K |
| CRI (Color Rendering Index) | 82 (Typ) |
| Flux @ 25°C, Current - Test | 59lm (37lm ~ 80lm) |
| Flux @ 85°C, Current - Test | - |
