LNJ727W83RAA
LED BLUE/GRN/ORG USS LED SMDManufacturer: Panasonic Electronic Components
Categories: LED Indication - Discrete
Quality Control: Learn More
The Panasonic Electronic Components LNJ727W83RAA is a discrete LED designed for indication applications. This component features independent control of three distinct colors: blue (472nm dominant, 470nm peak), green (535nm dominant, 525nm peak), and orange (620nm dominant, 630nm peak). Forward voltage specifications are 3.1V for blue and green, and 2V for orange, with typical test currents of 5mA for blue and green, and 10mA for orange. The component delivers luminous intensity ratings of 15mcd for blue, 80mcd for green, and 40mcd for orange. Mounted via surface mount technology, it is housed in a 6-SMD, No Lead package with a rectangular lens measuring 2.10mm x 1.15mm and a maximum height of 0.44mm. This versatile tri-color LED is suitable for use in automotive, industrial, and consumer electronics sectors requiring multi-color visual feedback within a compact footprint. It is supplied on tape and reel.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | 6-SMD, No Lead |
| Color | Blue, Green, Orange |
| Size / Dimension | 2.10mm L x 1.60mm W |
| Mounting Type | Surface Mount |
| Millicandela Rating | 15mcd Blue, 80mcd Green, 40mcd Orange |
| Configuration | Independent |
| Voltage - Forward (Vf) (Typ) | 3.1V Blue, 3.1V Green, 2V Orange |
| Lens Color | - |
| Current - Test | 5mA Blue, 5mA Green, 10mA Orange |
| Viewing Angle | - |
| Height (Max) | 0.44mm |
| Wavelength - Peak | 470nm Blue, 525nm Green, 630nm Orange |
| Wavelength - Dominant | 472nm Blue, 535nm Green, 620nm Orange |
| Supplier Device Package | - |
| Lens Transparency | - |
| Lens Style | Rectangle with Flat Top |
| Lens Size | 2.10mm x 1.15mm |
