LNJ624C4CRA
LED GREEN 3528 SMDManufacturer: Panasonic Electronic Components
Categories: LED Indication - Discrete
Quality Control: Learn More
Panasonic Electronic Components LNJ624C4CRA is a discrete green LED designed for surface mount applications within the 3528 package. This component emits light with a dominant wavelength of 530nm and a peak wavelength of 520nm, producing a typical forward voltage of 3.2V at 10mA test current. The LED provides a millicandela rating of 290mcd, featuring a round lens with a flat top, measuring 2.40mm in diameter. Its dimensions are 3.20mm in length and 2.80mm in width, with a maximum height of 2.10mm. Supplied in Tape & Reel (TR) packaging, this component is suitable for indication purposes across various industrial sectors including automotive and consumer electronics.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | 2-PLCC |
| Color | Green |
| Size / Dimension | 3.20mm L x 2.80mm W |
| Mounting Type | Surface Mount |
| Millicandela Rating | 290mcd |
| Configuration | Standard |
| Voltage - Forward (Vf) (Typ) | 3.2V |
| Lens Color | - |
| Current - Test | 10mA |
| Viewing Angle | - |
| Height (Max) | 2.10mm |
| Wavelength - Peak | 520nm |
| Wavelength - Dominant | 530nm |
| Supplier Device Package | 3528 |
| Lens Transparency | - |
| Lens Style | Round with Flat Top |
| Lens Size | 2.40mm Dia |
